DiClad Series Laminates

Views :
Update time : 2024-10-14

DiClad Series Laminates.jpg

DiClad Series Laminates

Rogers DiClad Series laminates are fiberglass-reinforced, PTFE-based composites designed for use as Printed Circuit Board substrates in High-Frequency Applications. The carefully controlled ratio of fiberglass to PTFE allows DiClad laminates to offer a range of low dielectric constant (Dk) values. A higher PTFE content results in a lower Dk and loss tangent, while increased fiberglass content enhances dimensional stability and registration. Unlike the CuClad® laminate series, DiClad laminates do not feature cross-plied constructions.

Benefits:

    ·         Stable Dk over frequency

    ·         Suitable for wide-band frequency applications

    ·         Higher gain in amplifier and antenna designs

    ·         Negligible performance drift caused by high moisture environments

    ·         First article success leads to faster time to market
