Taconic TLC-32 laminates

TLC-32 laminates are engineered to provide a cost-effective substrate suitable for a wide range of microwave applications. TLC-32 laminates offer superior electrical performance compared to thermoset laminates (e.g., FR-4, PPO, BT, polyimide, and cyanate ester). TLC-32’s construction also provides exceptional mechanical stability. TLC-32 laminates can be sheared, drilled, milled, and plated using standard methods for PTFE/woven fiberglass materials. The laminates are dimensionally stable and exhibit virtually no moisture absorption during fabrication.

Benefits:

    • Low Cost

    • Tightly Controlled Dk

    • Low Df

    • Excellent Dimensional Stability

    • High Flexural Strength

    • UL 94 V-0 Rating

Applications:

    • LNBs

    • Power Amplifiers

    • PCS/PCN Large Format Antennas

    • Passive Comp
